Lear VB511T Circuit Breaker | 32A, Single Pole, 240V

Name: Lear VB511T Circuit Breaker | 32A, Single Pole, 240V
SKU: SAS-1/32A
Availability: InStock

R30.00

The Lear VB511T Circuit Breaker delivers reliable single-pole protection with a 32A current rating and 240V AC operation. Unlike basic breakers, it features dual visual indicators—green for ON and red for OFF—alongside a single gray lever for intuitive control. With a 3kA breaking capacity and 6kV impulse withstand voltage, it’s built for dependable performance in residential and light commercial installations. Compliant with IEC 60947-2 and SANS 556-1 standards, this unit mounts easily on DIN rails and secures wiring via top and bottom screw terminals.

Lear VB511T Circuit Breaker | 32A, Single Pole, 240V Details:

Current Rating: 32A
Voltage Rating: 240V AC
Frequency: 50/60Hz
Breaking Capacity: Ics = 3kA, Icu = 3kA
Impulse Withstand Voltage: Uimp = 6kV
Rated Temperature: +40°C
Torque Specification: Max 2.5 Nm
Category: Cat. A
Standards Compliance: IEC 60947-2 and SANS 556-1
Poles: Single pole configuration
Lever: Single gray lever for circuit control
Indicator: ON (green) / OFF (red) visual status
Mounting Type: DIN rail compatible
Terminals: Screw-type for secure top and bottom wiring
Width: 7cm

What’s In The Box?

1 x Lear VB511T Circuit Breaker | 32A, Single Pole, 240V

8 in stock

Lear VB511T Circuit Breaker Overview

The Lear VB511T is a precision-engineered circuit breaker designed for mid-range single-phase applications. Its compact form, clear status indicators, and robust fault tolerance make it a dependable choice for electricians and panel installers.

Lear VB511T Circuit Breaker Benefits and Features

Mid-Range Protection: Ideal for lighting, appliance, and control circuits
Clear Status Indicators: ON/OFF color-coded lever for quick visual reference
High Fault Tolerance: 3kA breaking capacity with 6kV impulse resistance
Temperature Rated: Operates reliably up to +40°C
DIN Rail Mounting: Streamlined integration into standard enclosures
Secure Wiring: Screw terminals on both ends for stable connections
Compact Profile: 7cm width fits efficiently into residential distribution boards
Standards Compliance: Meets IEC and SANS requirements for safety and performance

Steps to Follow for Installing the Lear VB511T Circuit Breaker

Preparation:

Disconnect power supply before installation
Confirm DIN rail compatibility and available panel space
Prepare wiring according to load specifications

How to Install the Lear VB511T Circuit Breaker:

Mount the breaker onto the DIN rail
Connect wires to top and bottom screw terminals
Torque connections to a maximum of 2.5 Nm
Switch lever to OFF (red) position before energizing
Restore power and test functionality

Cleanup:

Tighten all terminal screws
Label breaker for identification
Dispose of packaging responsibly

A Few Scenarios Where the Product Can Be Used:

Protecting lighting circuits in residential panels
Isolating mid-load appliances or control systems
Integrating into compact electrical enclosures
Providing backup protection in low- to mid-load setups

Other Products You May Need for Your Electrical Installation

Health and Safety

Always install circuit breakers in accordance with local electrical codes and safety regulations. Ensure power is fully disconnected before handling. Use insulated tools and wear appropriate protective gear. Installation and maintenance should be performed by qualified personnel only.

Want more tips for installing a circuit breaker? Click here to learn more.

Additional information

Weight	0.196 kg
Dimensions	8 × 4 × 8 cm
